Workflow

Email inbox

Every tenant receives a dedicated inbox address (e.g. lou-orbits-neptune@ledgerlou.de) to which vendors or the internal team can forward documents. The address can be retrieved via GET /v1/inbox/address and is assigned automatically on first call.

What happens on receipt:

1. Filter attachments — Only PDF and image attachments (JPEG, PNG) are processed. Other file types are ignored. Maximum 20 attachments per email, max. 10 MB per file.
2. Store the document — The attachment is deduplicated by SHA-256 content hash and stored on disk. Duplicates are detected and skipped automatically.
3. OCR extraction — The document is converted to Markdown via Mistral OCR, then parsed into structured fields by an LLM (see next section).
4. Vendor matching — The extracted data (USt ID number, IBAN, name) is matched against the tenant’s existing vendors.
5. Invoice compliance check — The compliance checker verifies UStG §14 mandatory fields and classifies the document type.
6. Inbox entry — All results are stored as an inbox entry with status pending.

Inbox statuses:

Status	Meaning
pending	Document received, awaiting processing by user or agent
processing	Currently being processed
confirmed	Invoice created and posted
rejected	Document rejected (invalid, duplicate, or not an invoice document)

OCR extraction

OCR extraction runs in two stages: first, the document is converted to Markdown text via Mistral OCR. Then an LLM extracts the following structured fields:

Document classification:

Field	Description
document_type	Document type: invoice, credit_note, order_confirmation, delivery_note, quote, reminder, receipt, other

Vendor data:

Field	Description
vendor_name	Name of the vendor / issuer
vendor_address	Full address of the vendor
vendor_vat_id	USt ID number (e.g. DE123456789)
vendor_tax_id	Tax number (e.g. 27/123/45678)
vendor_iban	Vendor’s IBAN

Buyer data:

Field	Description
buyer_name	Name of the recipient of the supply
buyer_address	Address of the recipient of the supply

Invoice data:

Field	Description
invoice_number	Invoice number
invoice_date	Invoice date (YYYY-MM-DD)
delivery_date	Delivery / service date (YYYY-MM-DD)
due_date	Due date (YYYY-MM-DD)
total_net	Net amount
total_tax	VAT amount
total_gross	Gross amount
currency	Currency (default: EUR)

Line items:

Field	Description
line_items[].description	Description of the line item
line_items[].quantity	Quantity
line_items[].unit_price	Net unit price
line_items[].tax_rate	Tax rate as a decimal (e.g. 0.19)
line_items[].line_total	Line-item gross amount

Other:

Field	Description
payment_terms	Payment terms
reference_text	Reference text / memo for the transfer

Fields that cannot be detected in the document are returned as null. Tax rates that the LLM returns as percentages (e.g. 19 instead of 0.19) are normalized automatically.

Invoice compliance check (UStG §14)

After OCR extraction, LedgerLou automatically checks whether the document contains the formal mandatory fields per UStG §14. These fields are prerequisites for input-tax deduction.

What is checked:

#	Rule	Label
1	supplier_name	Name of the supplier
2	supplier_address	Address of the supplier
3	buyer_name	Name of the buyer
4	buyer_address	Address of the buyer
5	supplier_tax_id	Tax number or USt ID number
6	invoice_date	Invoice date
7	invoice_number	Invoice number
8	line_items	Quantity and nature of the supply
9	delivery_date	Date of delivery
10	net_amount	Net amount
11	tax_rate_and_amount	Tax rate and tax amount
12	gross_amount	Gross amount

Document-type detection: Non-invoice documents (quotes, delivery notes, order confirmations, etc.) are recognized as such. All checks are then marked as not_applicable so that these documents are not mistakenly treated as formally correct invoices.

Delivery date: If no explicit delivery date is present, the invoice date is assumed as the delivery date (common BMF practice). The checker marks this with a corresponding hint.

Result in the dashboard: The “Mandatory fields” column in the inbox table shows at a glance:

• Green 12/12 — all mandatory fields present
• Yellow 10/12 — mandatory fields missing
• Red with document type (e.g. “Quote”) — not an invoice document

Note: The invoice compliance check covers the essential formal mandatory fields per UStG §14 and is meant to surface missing fields early. It does not replace tax advice and does not claim to be exhaustive. Edge cases such as intra-Community supplies, reverse-charge cases (§13b UStG), margin-scheme taxation, or industry-specific additional requirements are currently not checked separately. In case of doubt, the invoice should be assessed by a tax advisor.

Document-type detection

The OCR system classifies every incoming document into one of the following types:

Type	Description
invoice	Invoice
credit_note	Credit note
order_confirmation	Order confirmation
delivery_note	Delivery note
quote	Quote
reminder	Reminder
receipt	Receipt
other	Other

Only invoice and credit_note are treated as invoice documents and checked against the mandatory fields. For all other document types, all checks are marked as not_applicable.

JSON schema (compliance_check)

The check result is stored as a compliance_check JSONB field on the inbox entry and is retrievable via GET /v1/inbox, GET /v1/inbox/:id, and the MCP tools list_inbox_documents and get_inbox_document.

{
  "document_type": "invoice",
  "is_invoice": true,
  "compliant": true,
  "passed": 12,
  "total": 12,
  "checks": [
    {
      "rule": "supplier_name",
      "label": "Name des Leistenden",
      "status": "pass"
    },
    {
      "rule": "delivery_date",
      "label": "Zeitpunkt der Lieferung",
      "status": "pass",
      "detail": "Rechnungsdatum als Leistungsdatum angenommen (BMF-Praxis)"
    }
  ]
}

Every check has one of three status values:

• pass — mandatory field present
• fail — mandatory field missing
• not_applicable — check not applicable (non-invoice document)

Example: invoice with missing fields

{
  "document_type": "invoice",
  "is_invoice": true,
  "compliant": false,
  "passed": 10,
  "total": 12,
  "checks": [
    { "rule": "supplier_name", "label": "Name des Leistenden", "status": "pass" },
    { "rule": "supplier_address", "label": "Anschrift des Leistenden", "status": "pass" },
    { "rule": "buyer_name", "label": "Name des Leistungsempfängers", "status": "fail" },
    { "rule": "buyer_address", "label": "Anschrift des Leistungsempfängers", "status": "fail" },
    { "rule": "supplier_tax_id", "label": "Steuernummer oder USt-IdNr.", "status": "pass", "detail": "USt-IdNr. vorhanden" },
    { "rule": "invoice_date", "label": "Rechnungsdatum", "status": "pass" },
    { "rule": "invoice_number", "label": "Rechnungsnummer", "status": "pass" },
    { "rule": "line_items", "label": "Menge und Art der Leistung", "status": "pass" },
    { "rule": "delivery_date", "label": "Zeitpunkt der Lieferung", "status": "pass", "detail": "Rechnungsdatum als Leistungsdatum angenommen (BMF-Praxis)" },
    { "rule": "net_amount", "label": "Nettobetrag", "status": "pass" },
    { "rule": "tax_rate_and_amount", "label": "Steuersatz und Steuerbetrag", "status": "pass" },
    { "rule": "gross_amount", "label": "Bruttobetrag", "status": "pass" }
  ]
}

Example: non-invoice document (quote)

{
  "document_type": "quote",
  "is_invoice": false,
  "compliant": false,
  "passed": 0,
  "total": 0,
  "checks": [
    { "rule": "supplier_name", "label": "Name des Leistenden", "status": "not_applicable", "detail": "Kein Rechnungsdokument" },
    { "rule": "supplier_address", "label": "Anschrift des Leistenden", "status": "not_applicable", "detail": "Kein Rechnungsdokument" }
  ]
}

Vendor matching

When a document arrives by email, LedgerLou tries to match the vendor from the OCR data to an existing payable automatically. Matching runs in three stages:

Stage 1 — USt ID number (highest priority)

If OCR extracted a USt ID number, a vendor with an identical USt ID number is searched. Matches are considered certain (confidence: 1.0).

Stage 2 — IBAN

If no USt ID number was found or no match exists, the extracted IBAN is matched against the IBAN fields of existing vendors.

Stage 3 — Name (fuzzy match)

If neither USt ID number nor IBAN leads to a match, the extracted vendor name is compared against existing vendors. A match is only proposed if similarity is above a threshold.

The result is stored as vendor_match on the inbox entry:

{
  "status": "matched",
  "vendor_id": "9fa85f64-...",
  "vendor_name": "Hetzner Online GmbH",
  "confidence": 1.0,
  "match_method": "vat_id"
}

With status: "not_found", no matching vendor was found — in this case a new vendor must be created before posting.

Duplicate detection

The Payables module prevents duplicate entries on several levels:

Vendors

When creating a vendor via POST /v1/vendors, the following are checked:

• Name (case-insensitive, Unicode-normalized) — an identical name is rejected
• USt ID number — an identical USt ID number is rejected
• Tax number — an identical tax number is rejected

The error response contains the ID of the existing vendor, so that an agent or user can refer to it directly.

Invoices

When creating an incoming invoice via POST /v1/invoices, the combination of vendor ID and invoice number is checked for uniqueness. A duplicate invoice number for the same vendor is rejected.

Inbox documents

On email receipt, the content hash (SHA-256) of each document is computed. If the same document is received again (e.g. by multiple forwards), the duplicate entry is silently skipped (ON CONFLICT DO NOTHING).

Status lifecycle (invoices)

Status	Meaning
draft	Invoice captured but not yet posted (no intent)
open	Linked to the journal, fully open
partially_paid	Partial payment received
paid	Fully paid
overdue	Open invoice past its due date
